SKU: nhu-r5ac-lite
Availability: Out of Stock
Brand: Ubiquiti
Category: Access Points
100% Guarantee Safe Checkout
The Ubiquiti Rocket 5AC PTMP Lite is a compact, weather-rated 5 GHz base station engineered for Point-to-MultiPoint (PtMP) and Point-to-Point (PtP) deployments. Powered by airMAX™ ac technology, it delivers over 500 Mbps real-world throughput and supports 50+ concurrent clients, making it ideal for WISPs, campus networks, and outdoor broadband access.
Key highlights:
For installers: compact dimensions, low power consumption (8.5W max), and a wide operating temperature range (-40 to 80°C) ensure year-round reliability in harsh outdoor environments.
| Antenna | Requires compatible airMAX antennas (sold separately) |
| Documentation | Quick Start Guide and tech specs available on Ubiquiti support site |
| Management / Firmware | airOS \/ airMAX management |
| Enclosure | Outdoor UV\u2011stabilized plastic |
| Ethernet | 1 \u00d7 10\/100\/1000 RJ-45 |
| Power Method | Passive PoE (24V) — Pairs 4,5+; 7,8 Return |
| PoE Adapter | 24V,0.5A Gigabit PoE Adapter (included) |
| Frequency Band | 5 GHz |
| Throughput | 500+ Mbps (typical,airMAX AC) |
| Client Capacity | 50+ concurrent clients (typical) |
| Spectral Analysis | Dedicated spectral analysis radio (built-in) |
| Wireless Standard / Protocol | airMAX\u2122 ac |
| Frequency Band | 5 GHz |
| Certifications | CE,FCC,IC |
| Mounting | Pole mount kit included (U\u2011bolts and clamps) |
| Dimensions | 198.5 \u00d7 86.4 \u00d7 44.1 mm (7.82 \u00d7 3.40 \u00d7 1.74 in) |
| Weight | 295 g (10.41 oz) |
| Dimensions (mm) | 198.5 x 86.4 x 44.1 mm |
| Operating Humidity | 5 to 95% (non\u2011condensing) |
| Operating Temperature | -40 to 80\u00b0C (-40 to 176\u00b0F) |
| Max Power Consumption | 8.5 W |
| Power Requirements | Passive PoE,24V |
| Power Consumption (W) | 8.5 |
| Device Type | Outdoor PtMP BaseStation \/ Wireless Radio |
| Model | Rocket 5AC PTMP Lite (R5AC-Lite) |
| Model Number | R5AC-Lite |
| Wireless Standards | airMAX ac |
| Ethernet Ports | 1 x 10\/100\/1000 RJ-45 |
