SKU: cubi nuc ai 1umg-012bau
Availability: In Stock
Brand: MSI
Category: Desktop Computers
100% Guarantee Safe Checkout
The MSI Cubi NUC AI 1UMG-012BAU is a cutting-edge barebone mini PC designed for high-performance computing in an ultra-compact form factor. Powered by the advanced Intel Core Ultra 7 155H processor featuring 16 cores and 22 threads, this mini PC delivers robust multitasking capabilities and AI-enabled processing thanks to its integrated Neural Processing Unit (NPU).
This black chassis device supports dual-channel DDR5 memory up to 64GB (user-installed) and flexible storage options with dual M.2 slots (commonly 2280 and 2242). Its rich I/O includes two Thunderbolt 4 ports with DisplayPort 1.4 alt-mode and power delivery, dual HDMI outputs supporting 4K at 60Hz, and two Intel I226V 2.5Gb Ethernet LAN ports for lightning-fast wired networking.
Wireless connectivity is powered by the Intel AX211 Wi-Fi 6E module with Bluetooth 5.3, providing next-generation wireless speeds and reliability. The front panel features ultra-fast USB 3.2 Gen 2 Type-C and Type-A ports making peripheral connectivity seamless.
This barebone system ships with a 120W power adapter and comes backed by a 3-year warranty. Its compact dimensions (119.6 x 115.2 x 37.5 mm) and lightweight design offer versatile deployment options including VESA mounting.
Ideal for professionals and enthusiasts seeking a compact desktop with exceptional performance, expandability, and connectivity, the MSI Cubi NUC AI 1UMG-012BAU is a powerful foundation to build your custom PC configuration.
| Graphics | Integrated Intel Graphics |
| Video Output | HDMI 2.1 outputs (4K@60Hz) |
| LAN Ports | Intel I226V 2.5Gb Ethernet |
| USB Ports (Front) | 1x USB 3.2 Gen 2 Type-C (10 Gbps),USB 3.2 Gen 2 Type-A (10 Gbps) |
| Thunderbolt Ports | Thunderbolt 4 (DP 1.4 alt-mode,PD-out 15W) |
| Storage Supported | M.2 slots (2280 and 2242) |
| Memory Supported | DDR5 SO-DIMM slots,up to 64 GB |
| Boost Clock | 4.80 GHz |
| effective_memory_slots | 2 |
| aio_form_factor | Mini PC |
| cpu_cache_mb | 24 |
| SKU | 1UMG-012BAU |
| Processor Model | Intel Core Ultra 7 155H |
| processor_socket | Intel SoC (integrated,no traditional socket) |
| Processor Threads | 22 |
| Base Clock | 1.40 GHz |
| Processor Model | Intel Core Ultra 7 155H |
| Processor Cores | 16 |
| Socket Type | Intel SoC (integrated,no traditional socket) |
| Bluetooth Version | Bluetooth 5.3 |
| memory_type | DDR5 |
| boost_clock_speed_ghz | 4.8 |
| base_clock_speed_ghz | 1.4 |
| CPU Threads | 22 |
| CPU Cores | 16 |
| Weight | 0.55 Kg (1.21 lbs) |
| Dimensions (WxDxH) | 119.6 x 115.2 x 37.5 mm (4.71 x 4.54 x 1.48 in) |
| Ports | Thunderbolt 4 (DP 1.4 alt-mode,PD-out 15W); 1x USB 3.2 Gen 2 Type-C (10 Gbps); 2x USB 3.2 Gen 2 Type-A (10 Gbps); 2x HDMI 2.1 outputs (4K@60Hz); 2x Intel I226V 2.5Gb Ethernet |
| weight_kg | 0.55 |
| Dimensions (mm) | 119.6 x 115.2 x 37.5 mm |
| Power Adapter | 120W AC Adapter |
| Operating System | Windows 11 Home\/Pro (recommended Pro for business) |
| Operating System Support | Windows 11 Home\/Pro |
| Operating System | Windows 11 Home\/Pro (recommended Pro for business) |
| Wireless | Intel Wi-Fi 6E AX211,Bluetooth 5.3 |
| ethernet_speed_gbps | 2.5 |
| wi_fi_standard | 802.11ax 6E |
| Networking | Intel I226V 2.5Gb Ethernet; Intel Wi-Fi 6E AX211; Bluetooth 5.3 |
| Cache | 24 MB |
| max_memory_capacity_gb | 64 |
| Warranty | 3 Years |
| Warranty (years) | 3 |
| Storage Interface | PCIe NVMe |
| Storage Type | NVMe SSD |
